Press systems for plastics and composites

Press:
7.000 kN, 1.300 x 2.100 mm, 420°C

Special features:
controlled hydraulics, fully automated separation foil (stainless steel) loading station with integrated lifter, separation foil rewind function, cutting station

Press:
6000 kN, 600 x 600 mm, 250°C

Special features:
heat plate cooling via high performance closed cooling system

Press:
1.000kN, 500 x 500 mm, 300 ° C

Special features:
easily removable heating plates with cooling function, robots with special gripping system for material handling between charging station, IR pre-heating station and press

Press:
5.400kN, 1000 x 800 mm, 240°C

Special features:
lowest press velocity is 0,05mm/s, easy removable heating plates with cooling function, shuttle system

Press:
2.000 kN, 800 x 600 mm, 400°C

Special features:
IR pre-heating station, material transfer system, easy removable heating plates with cooling function

Press:
2000 kN, 900 x 600 mm, 300°C

Special features:
can be flexibly extended with a pre-heating station and a material transfer system

Press:
3.200 kN, 1.600 x 850 mm, 450°C

Special features:
movable cooling plates, temperature accuracy on heat plate surface at 250°C < 1,5K

Stations:
charging station, heating station, forming station and material transport system

Press:
4.000 kN, 1.800 x 900 mm

Special features:
Material unwinding station, cutting station, loading station, pre- heating station, forming press, unloading station and material transport system

Presse:
500 kN, 500 x 500, 400°C

Besondere Merkmale:
Werkzeugzuhalteeinrichtung beim Öffnen der Presse, einfahrbare Kühlplatten, Präzisionsheizplatten ΔT=±1K

Press:
2.000 kN, 900 x 600 mm, 300°C

Special features:
Pre-heating station with contact heating and material transfer system cooling function and retractable heating plate

Press:
3.200 kN, 1.200 x 800 mm, 400°C

Special features:
IR pre-heating station, material transfer system, cooling function and retractable heating plate

Press:
31.000 kN, 1.350 x 4.500 mm, 250°C

Special features:
Hot water heating using a tempering system

Press:
24.000 kN, 2.600 x 1.400

Special features:
2 daylights, oil tempering equipment for heating and cooling

Press:
3000 kN, 1.500 x 600 mm, 300°C

Special features:
IR pre-heating station (cased), material transfer system

Press:
3.000 kN, 1.350 x 850 mm, 180°C

Special features:
Pre heating station equipped with convection oven, material transfer system

Press:
430 kN, 500 x 600 mm, 300°C

Special features:
IR pre-heating station (cased), material transfer system

Press:
2.000 kN, 780 x 500 mm, 480°C

Special features:
heating up rate of 30 K/min, cooling function

Press:
2.014 kN, 450 x 450 mm, 450°C

Special features:
cooling function
